TempoLST Hybrid TPT

An LST radiator for heating, cooling and ventilation in one

Outputs more information
  • All the benefits of Tempo, but even more compact and more powerful with DBH
  • A simple and safe radiator for heat pumps and low temperature systems
  • Eco-friendly light cooling with reverse cycle heat pumps providing cooled water

TPT - Temperature control configuration

  • The room temperature is set on the control panel
    • Heating from 16 to 26°C
    • Cooling from 16 to 26°C
  • The thermoelectric motor can be fitted completely invisibly within the heating unit (optional)
  • Control of the boosters and the thermoelectric motor
  • Modulating effect based on the difference between set temperature and measured temperature
  • Manual boost possible
  • 30 years warranty

Outputs

Tempo Hybrid TPT Outputs

Height (H) [mm] Length (L) [mm] Type
wdt_ID wdt_created_by wdt_created_at wdt_last_edited_by wdt_last_edited_at Height (H) [mm] Length (L) [mm] Type Comfort Heating (75/65/20) [Watts] Comfort Heating (55/45/20) [Watts] Comfort Heating (45/35/20) [Watts] Comfort Heating (35/30/20) [Watts] Comfort Cooling (16/18/27( [Watts] Comfort Sound Pressure [dB(A)] Electric Power Consumption [Watts] Ordering Code
1 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 400 11 - - - - - - -
2 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 400 16 - - - - - - -
3 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 400 21 - - - - - - -
4 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 500 11 943 534 337 203 158 30.0 5.1 TEMW.030 050 11.XXX + DBHS.LLL TT/TPT
5 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 500 16 - - - - - - -
6 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 500 21 - - - - - - -
7 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 600 11 1223 693 438 263 205 30.0 6.8 TEMW.030 060 11.XXX + DBHS.LLL TT/TPT
8 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 600 16 1503 851 538 323 230 30.0 7.2 TEMW.030 060 16.XXX + DBHS.LLL TT/TPT
9 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 600 21 1935 1125 725 447 251 30.0 7.2 TEMW.030 060 21.XXX + DBHS.LLL TT/TPT
10 Katie 11/10/2024 11:26 AM Katie 11/10/2024 11:26 AM 300 700 11 1498 484 536 322 251 30.0 7.9 TEMW.030 070 11.XXX + DBHS.LLL TT/TPT


Composition of the order code​​​

Hover over the parts below to find out what they stand for​​​​​

TEMW.090 050 16.101 DBHS 050 16 TPT

Standard Delivery

All Tempo Hybrids are made to order

Split deliveries option available

Please contact our customer service team to discuss your requirements

Package includes:

  • Low-H2O heat exchanger with wall brackets and fixing kit, air vent 1/8” and drain plug 1/2”
  • Casing for connection left or right at low level
  • Cover plate in stainless steel effect for the side panel at the opposite end from the valve
  • Easy to install DBH unit with operation, control and 24VDC power supply
  • Clear installation instructions

This heater is not equipped with a condensation monitor, it has to be integrated into the installation (only for cooling)

Dimensions

Tempo_wall_dimensions_DA

Standard colours

other colours : Tempo LST Hybrid TPT

Subtle & Discreet

Also available:

Tempo LST Hybrid TPT: Projects
