TempoLST Continuous Hybrid ACO

Seamless warmth from wall-to-wall

Outputs more information
  • All the benefits of Tempo Continuous, but even more compact and more powerful with DBH
  • The ultimate radiator solution for low flow temperatures associated with renewable energy technology
  • Low-cost light cooling when used with reverse cycle heat pumps providing cooled water
  • Breeze functionality offering ambient air circulation

Tempo Continuous Hybrid ACO switches fully automatically between heating and light cooling

You don’t have to do anything at all to switch between heating and cooling. Thanks to its accurate room and water temperature sensors, the Hybrid heater will change automatically to cooling mode when cold water is supplied, and back to heating mode when hot water is supplied.

  • The default auto-changeover ACO mode with 3 operating positions:
  • Speed 1 - max. 26 dB(A)
  • Speed 2 - max. 30 dB(A)
  • Speed 3 - maximum position for rapid heating or cooling

Breeze function: fan activated airflow that doesn’t require any cool water.

Heating, Cooling, Breeze

DBH_heating



DBH_cooling



DBH_breeze





  • 30 years warranty
  • European Design Awards

Outputs

Tempo Continuous Hybrid ACO Outputs

Height (H) [mm] Length (L) [mm] Type
wdt_ID Height (H) [mm] Length (L) [mm] Type wdt_created_by wdt_created_at wdt_last_edited_by wdt_last_edited_at Comfort Heating (75/65/20) [Watts] Comfort Heating (55/45/20) [Watts] Comfort Heating (45/35/20) [Watts] Comfort Heating (35/30/20) [Watts] Comfort Cooling (16/18/27( [Watts] Comfort Sound Pressure [dB(A)] Electric Power Consumption [Watts] Ordering Code
1 300 400 11 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM - - - - - - -
2 300 400 16 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM - - - - - - -
3 300 400 21 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM - - - - - - -
4 300 500 11 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM 943 534 337 203 158 30.0 5.1 TEDW.030 050 11.XXX + DBHS.LLL TT/ACO
5 300 500 16 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM - - - - - - -
6 300 500 21 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM - - - - - - -
7 300 600 11 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM 1223 693 438 263 205 30.0 6.8 TEDW.030 060 11.XXX + DBHS.LLL TT/ACO
8 300 600 16 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM 1503 851 538 323 230 30.0 7.2 TEDW.030 060 16.XXX + DBHS.LLL TT/ACO
9 300 600 21 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM 1935 1125 725 447 251 30.0 7.2 TEDW.030 060 21.XXX + DBHS.LLL TT/ACO
10 300 700 11 Katie 09/10/2024 09:29 AM Katie 09/10/2024 09:29 AM 1498 484 536 322 251 30.0 7.9 TEDW.030 070 11.XXX + DBHS.LLL TT/ACO


Composition of the order code​​​

Hover over the parts below to find out what they stand for​​​​​

TEDW.020 060 10.101 DBHS 060 10 ACO

Standard Delivery

All Tempo Hybrids are made to order. Split deliveries option available

Please contact our customer service team to discuss your requirements

Package includes:

  • Low-H2O heat exchanger with wall brackets and fixing kit, air vent 1/8” and drain plug 1/2”
  • Casing for connection left or right at low level
  • Cover plate in stainless steel effect for the side panel at the opposite end from the valve
  • Easy to install DBH unit with operation, control and 24VDC power supply
  • Clear installation instructions

This heater is not equipped with a condensation monitor

It has to be integrated into the installation (only for cooling)

Dimensions

Tempo_freestanding_dimensions_DA

Standard colours

other colours : Tempo LST Continuous Hybrid ACO
