GuardianLST

Strong, single-piece casing for fast installation

Outputs more information

The Guardian LST is designed to be the UK’s fastest and easiest LST radiator to install. Easy to store and available in an extensive range of sizes with powerful outputs.

  • Lower energy consumption and maximum heat emission through the Low-H2O ultra-conducting heat exchanger
  • Safety features include rounded corners and safe to touch surface, even at high flow temperatures
  • Can offer cooling via Jaga's Dynamic Boost Hybrid (DBH) technology and ventilation via Jaga's oXygen system
  • 30 years warranty

Outputs

Guardian LST Outputs

Height (H) [mm] Length (L) [mm] Depth (D) [mm] Casing Model (WT/FT)
wdt_ID wdt_created_by wdt_created_at wdt_last_edited_by wdt_last_edited_at Radiator Height (H) [mm] Length (L) [mm] Depth (D) [mm] Casing Model (WT/FT) Heating (75/65/20) [Watts] Heating (55/45/20) [Watts] Order code
1 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 440 119 FT 193 90 GUAR 040 044 119.XXX /FT
2 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 440 119 WT 234 109 GUAR 040 044 119.XXX /WT
3 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 440 169 FT 277 128 GUAR 040 044 169.XXX /FT
4 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 440 169 WT 351 164 GUAR 040 044 169.XXX /WT
5 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 440 219 FT 339 160 GUAR 040 044 219.XXX /FT
6 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 440 219 WT 446 206 GUAR 040 044 219.XXX /WT
7 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 640 119 FT 385 179 GUAR 040 064 119.XXX /FT
8 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 640 119 WT 467 218 GUAR 040 064 119.XXX /WT
9 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 640 169 FT 553 256 GUAR 040 064 169.XXX /FT
10 jagadmin 29/08/2024 08:35 AM jagadmin 29/08/2024 08:35 AM Guardian 400 640 169 WT 703 329 GUAR 040 064 169.XXX /WT


Composition of the order code​​​

Hover over the parts below to find out what they stand for​​​​​

GUAR 040 064 119 233 YY

Standard Delivery

  • Low-H2O heat exchanger with wall brackets and fixing kit
  • Extended air vent 1/8” and drain plug 1/2”
  • Easy to assemble casing

Standard colours

other colours : Guardian LST
