Clima Canal 192-pipe

Complete climate control

Outputs more information
Packshot_Clima Canal H019
  • For low flow temperature heating and deep cooling
  • ventilate comfortably
  • with energy-efficient EC-motor
  • Hybrid Heating

Outputs

Clima Canal 19

Height (H) [mm] Length (L) [mm] Width (W) [mm] Speed [V]
wdt_ID wdt_created_by wdt_created_at wdt_last_edited_by wdt_last_edited_at Height (H) [mm] Length (L) [mm] Width (W) [mm] Speed [V] Heating (75/65/20) [Watts] Heating (55/45/20) [Watts] Heating (45/35/20) [Watts] Heating (35/30/20) [Watts] Light Cooling (16/18/27) [Watts] Deep Cooling (7/12/27) [Watts] Deep Cooling (7/12/27) [Watts] Sound Pressure [dB(A)] Electric Power Consumption [Watts] Air Flow [m3/h] Ordering Code
1 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1050 340 2 1245 743 489 308 164 378 267 17 1.5 97 CCAF 019 105 34.XXX
2 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1050 340 4 1965 1172 772 486 321 729 522 21 2.7 167 CCAF 019 105 34.XXX
3 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1050 340 6 2567 1531 1008 635 474 1069 775 27 4.8 236 CCAF 019 105 34.XXX
4 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1050 340 8 3102 1850 1218 768 626 1405 1030 35 9.3 309 CCAF 019 105 34.XXX
5 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1050 340 10 3593 2143 1411 889 777 1739 1290 40 15 351 CCAF 019 105 34.XXX
6 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1200 340 2 1548 923 608 383 204 469 332 19 3.2 82 CCAF 019 120 34.XXX
7 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1200 340 4 2442 1457 959 604 398 906 649 22 6.7 179 CCAF 019 120 34.XXX
8 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1200 340 6 3189 1902 1253 789 589 1328 962 28 12.1 260 CCAF 019 120 34.XXX
9 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1200 340 8 3854 2299 1514 954 778 1746 1280 36 18.4 351 CCAF 019 120 34.XXX
10 Katie 28/03/2025 03:31 PM Katie 28/03/2025 03:31 PM 190 1200 340 10 4464 2662 1754 1105 965 2160 1602 41 24 401 CCAF 019 120 34.XXX


Composition of the order code​​​

Hover over the parts below to find out what they stand for​​​​​

CCAF 019 280 034 XXX

Standard Delivery

  • casing in Sendzimir-galvanised steel sheet (RAL7024) with height adjustment and stainless steel grille support
  • grille(s): anodised aluminium or wood
  • dynamic heat exchanger
  • thermal activator(s), (tangential mini activator) 24 VDC
  • stainless steel flexible connections 1/2", 15 cm long
  • height-adjustable base 0 < 4.5 cm
  • fine adjustment 0 > 0.8 cm (not included with Clima Canal 019)
  • cover plates

Composition

CCAF_EXP_019_105_2P 1

  1. protection panel: panel for mounting and site protection
  2. valves Cover plate
  3. stainless steel flexible connections 1/2", 15 cm long stainless steel flexible hoses allow the internal mechanism to be removed completely for easy cleaning
  4. electrical connection on the inside
  5. condensate tray, for drainage (ø 2 cm) of condensate water
  6. height-adjustable base 0 > 4.5 mm provided with acoustic decoupling
  7. Hydronic & electrical connection always left-hand side
  8. Duct with stainless steel grille supportcoated housing in sendzimir galvanised steel plate
  9. optional nozzle(s) for ventilation duct
  10. inner housing
  11. fans
  12. dynamic heat exchanger 2-pipe
  13. Grille aluminium and wooden grilles in a variety of colours and materials

Dimensions

Clima_Canal_019_dimensions_DA
