MiniWall

Strikingly inconspicuous

Outputs more information
Packshot_Mini
  • Extremely well suited to spaces with large windows and for dwarf walls under window seats
  • Heights from 8cm!
  • Beautiful in combination with the free-standing Mini for glazed façades
  • Low-H2O technology with a super conductive and ultra fast heat exchanger for low energy consumption and maximum heat emission
  • Safe surface temperature
  • 30 years warranty

Outputs

Mini Outputs

Height (H) [mm] Length (L) [mm] Type
wdt_ID wdt_created_by wdt_created_at wdt_last_edited_by wdt_last_edited_at Height (H) [mm] Length (L) [mm] Type Heating (75/65/20) [Watts] Heating (70/50/20) [Watts] Heating (55/45/20) [Watts] Heating (45/40/20) [Watts] Ordering code
1 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 600 9 255 186 124 82 MINW.00806009.XXX
4 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 700 9 298 217 144 96 MINW.00807009.XXX
7 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 800 9 340 248 165 110 MINW.00808009.XXX
10 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 900 9 383 279 186 123 MINW.00809009.XXX
13 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 1.000 9 425 310 206 137 MINW.00810009.XXX
16 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 1.100 9 468 341 227 151 MINW.00811009.XXX
19 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 1.200 9 510 372 247 164 MINW.00812009.XXX
22 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 1.400 9 595 434 288 192 MINW.00814009.XXX
25 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 1.600 9 680 496 330 219 MINW.00816009.XXX
28 Katie 29/01/2025 12:12 PM Katie 29/01/2025 12:12 PM 80 1.800 9 765 557 371 247 MINW.00818009.XXX


Composition of the order code​​​

Hover over the parts below to find out what they stand for​​​​​

MINW 060 10 XXX

Standard Delivery

  • Low-H2O heat exchanger, air vent 1/8" and drain plug 1/2"
  • casing in one piece for connection left or right
  • wall brackets in the same colour as the casing

Dimensions

Mini_wall_dimensions_DA
